GN 115.8 Cam Latches with Hook Stainless Steel Housing, with Plastic Operating Elements

Cam Latches with Hook GN 115.8: Stainless Steel Housing, with Plastic Operating Elements
Type: RG - With hollow knurled knob GN 7336
Material: N - Stainless steel
Identification no.: 2 - With latch bracket
Stainless-Steel

Product Family Stainless Steel

Standard parts made of rustproof stainless steel have been designed for use in the food sector, in the chemical industry, for aggressive ambient conditions or for outdoor use.

  • corrosion-resistant
  • precise fit
  • environmentally friendly
Show all Stainless Steel products
Operating Instruction GN 115.8 Construction and Assembly Instructions IP Protection Classes Plastic Characteristics Stainless Steel Characteristics

Product description

Cam latches with hook GN 115.8 and latch bracket are mainly used for sliding doors and flaps. The latching action is in a radial direction to the axis of rotation, resulting in a wide variety of different uses.

The latches GN 115.8 are supplied with loosely enclosed hook.

Specification

Cam latch housing
Stainless steel AISI 303N

Operating elements
Plastic, Polyamide (PA)
Black, matte finish

Other parts
Stainless steel AISI 304

Cover cap
Plastic
Light gray, matte finish

Protection class IP 65

RoHS

On request

  • Cam latches with other hook distance A
  • Hook with other pivoting radius R
GN 115.8 Stainless Steel Cam Latches with Hook, with Plastic Operating Elements sketch
Hide technical drawing
GN 115.8 Stainless Steel Cam Latches with Hook, with Plastic Operating Elements sketch

Part Options / Table

Type

RGWith hollow knurled knob GN 7336
KGWith wing knob
HGWith lever

Hook version

H1Pivoting radius R=28mm

Identification no.

1Without latch bracket
2With latch bracket
Show / Hide columns

Metric

Dimensions in: Inch (change to Metric)
Hook distance Adh
0.711.100.16

Build & Price
Type



Hook distance A
Hook version

Material

Identification no.


Type



Hook distance A
Hook version

Material

Identification no.


Selected Part

Total (net)
Mex$1,362.00
Available within 2 weeks
Create Project List
Save as Favorites
Recommend a product
Please note our quantity discounts (Mexican Pesos).
MinMaxPrice
199Mex$1,362.00
100249Mex$1,248.50
250499Mex$1,135.00
≥ 500Mex$1,021.50
Prop 65: Not compliant
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
RoHS: Compliant
This article is RoHS-compliant in application of Annex III., which means it complies with EU Directive 2011/65/EU, including extension (2015/863/EU), for restricting the use of certain hazardous substances in electrical and electronic devices. The Directive regulates the use of hazardous substances in devices and components. The implementation in national law is summarily described with RoHS(Restriction of (the use of certain) hazardous substances)).
Weight: 0.121 lbs
If weight is not listed, please contact our Sales Department for additional information regarding weight.
Phone: +52(81)2721-4021

CAD Download

CAD Download Tutorial

Need Help?

Our service team is available from Monday to Friday between 8:00 AM and 6:00 PM Central Time: +52(81)2721-4021

Special Requests | Contact our sales team

GN 115.8-RG-18-H1-N-1GN 115.8-KG-18-H1-N-1GN 115.8-HG-18-H1-N-1GN 115.8-RG-18-H1-N-2GN 115.8-KG-18-H1-N-2GN 115.8-HG-18-H1-N-2
